81
7.3 Event Scheduling
The scheduling function enables to setup scheduled events including power on /
power off. It enables to be “self-management” projector.
• You can schedule the following control events: Power, Input Source,
My Image, Messenger, Slideshow. (
56)
• The power on / off event has the lowest priority among the all events that are
dened at the same time.
• There are 3 types of Scheduling, 1) daily 2) weekly 3) specic date. (
55)
• The priority for scheduled events is as follows 1) specic date 2) weekly 3)
daily.
• Up to ve specic dates are available for scheduled events. Priority is given to
those with the lower numbers when more than one event has been scheduled
for the same date and time (e.g., ‘Specic date No. 1’ has priority over ‘Specic
date No. 2’ and so on.
• Be sure to set the date and time before enabling scheduled events. (
58)
NOTE
7. Other Functions

Table of Contents

Other manuals for Hitachi CP-A220N

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Hitachi CP-A220N and is the answer not in the manual?

Hitachi CP-A220N Specifications

General IconGeneral
Matrix size0.63 \
Matrix type3-panel (p-Si TFT active)
Number of colors16.78 million colors
Native aspect ratio4:3
Projection distance- m
Projection technology3LCD
Contrast ratio (typical)2000:1
Digital gamma correctionYes
Screen size compatibility- \
Projector native resolutionXGA (1024x768)
Vertical synchronization (max)120 kHz
Vertical synchronization (min)50 kHz
Horizontal synchronization (max)106 kHz
Horizontal synchronization (min)15 kHz
Throw ratio0.3:1
Focal length range- mm
Lamp power210 W
Light source typeLamp
Service life of light source3000 h
Service life of light source (economic mode)5000 h
Full HDNo
Supported video modes1080i, 1080p, 480i, 480p, 576i, 720p
Analog signal format systemNTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 768 (WXGA), 1280 x 800 (WXGA), 1360 x 768 (WXGA), 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
RMS rated power10 W
Number of built-in speakers1
USB connector typeUSB Type-A, USB Type-B
Serial interface typeRS-232
USB 2.0 ports quantity2
VGA (D-Sub) ports quantity3
Component video (YPbPr/YCbCr) in0
Optical disc player typeNot included
Noise level35 dB
CertificationUL, C-UL, FCC, CE
Noise level (economic mode)28 dB
Product colorWhite
Cable lock slot typeKensington
Power sourceAC
AC input voltage90 - 264 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.3 W
Power consumption (typical)310 W
Operating temperature (T-T)5 - 35 °C
Weight and Dimensions IconWeight and Dimensions
Depth303 mm
Width344.93 mm
Height85.09 mm
Weight3900 g
