Introduction
Part names
(1) Lamp cover (56)
The lamp unit is inside.
(2) FOCUS ring (20)
(3) ZOOM ring (
20)
(4) Control panel (
5)
(5) Elevator buttons (x 2) (
20)
(6) Elevator feet (x 2) (
20)
(7) Remote sensor (
15)
(8) Lens (
60)
(9) Intake vents
(10) Filter cover (
58)
The air filter and intake vent are
inside.
(11) Exhaust vent
(12) AC IN (AC inlet) (
13)
(13) Rear panel (
5)
(14) Security bar (
14)
(15) Security slot (
14)
HOT!
HOT!
(11)
(1)
(2) (3) (4)
(7)
(9)
(8)
(10)
(6)
(5)
(6)
(14)
(12)
(15)
(13)
(5)
(9)
►Do not open or remove any portion of the product, unless the
manuals direct it.
►Do not subject the projector to unstable conditions.
►Do not apply a shock or pressure to this product.
►Do not look into the lens and the openings on the projector while the lamp is
on.
WARNING
►Do not touch around the lamp cover and the exhaust
vents during use or just after use, since it is too hot.
►Do not attach anything onto the lens because it could damage the lens,
such as melting the lens.
CAUTION
(continued on next page)
To Next Page
