Hitachi CP-X8170 User Manual

50
IMAGE menu
Item Description
OVER SCAN
Using the ◄/► buttons adjusts the over-scan ratio.
Small (It magnies picture)
ó
Large (It reduces picture)
• This item can be selected only for a video, s-video and component
video signal.
• For an HDMI
TM
signal, this item can also be selected if either (1) or
(2) applies.
(1) HDMI FORMAT item in the INPUT menu for selected port is set
to VIDEO.
(2)
HDMI FORMAT item in the INPUT menu for selected port is set to
AUTO, and the projector recognizes that it receives video signals.
V POSITION
Using the ◄/► buttons adjusts the vertical position.
Down
ó
Up
• Over-adjusting the vertical position may cause noise to appear on
the screen. If this occurs, please reset the vertical position to the
default setting. Pressing the RESET button when the V POSITION
is selected will reset the V POSITION to the default setting.
• When this function is performed on a video signal or an s-video
signal, the range of this adjustment depends on OVER SCAN
(

above) setting. It is not possible to adjust when OVER SCAN is
set to 10.
• This function is unavailable for a signal from the LAN, USB TYPE A
/ B or HDMI 1 / 2 port.
H POSITION
Using the ◄/► buttons adjusts the horizontal position.
Right
ó
Left
•
Over-adjusting the horizontal position may cause noise to appear on
the screen. If this occurs, please reset the horizontal position to the
default setting. Pressing the RESET button when the H POSITION is
selected will reset the H POSITION to the default setting.
• When this function is performed on a video signal or an s-video
signal, the range of this adjustment depends on OVER SCAN
(

above) setting. It is not possible to adjust when OVER SCAN is
set to 10.
•
This function is unavailable for a signal from the LAN, USB TYPE
A / B or HDMI 1 / 2 port.
(continued on next page)
