Hitachi DB3DL2 - Specifications

11
English
2. Battery charger (UC3SFL)
Battery installation hole
Pilot lamp
Plug
Nameplate
Cord
Fig. 2
SPECIFICATIONS
1. Cordless driver drill (DB3DL2)
Motor DC motor
No-load speed
Low 200 / min
High 600 / min
Capacity
Drilling
Metal (Thickness
1/32″ (1.0 mm))
13/64″ (5 mm)
(Mild steel or aluminum)
Screw
Driver
Wood screw #8 × 1-1/2″ (3.8 mm × 38 mm)
Small screw 3/16″ (5 mm)
Bit shank size 1/4″ (6.35 mm) Hex.
Battery
Model EBM315
Type Lithium - ion battery
Voltage DC 3.6 V
Charging & discharging frequency About 500 times
Weight 1.0 lbs (0.45 kg)
2. Battery charger (UC3SFL)
Input power source Single phase: AC 120 V 60 Hz
Charging time
Approx. 30 min.
(At a temperature of 68°F (20°C))
Charging voltage DC 3.6 V
Charging current DC 3.0 A
Weight 0.7 lbs. (0.3 kg)
NOTE: The charging time may vary according to temperature and power source voltage.
