HTA-DD3
REPLACEMENT PARTS LIST
PRODUCT SAFETY NOTE: Components marked with a have special characteristics important to safety. Before replacing any of these
components, please read carefully the Service Manual.
ABBREVIATIONS Capacitors ............. CK45: Disk Capacitor, CK73: Chip Capacitor (E-12 series), CK14:Axial Capacitor,
CE:Electrolytic, CQ:Polyester Film Capacitor, CC73:Chip Capacitor (E-24 series)
Resistors ................ RD: Axial Resistor, RN: Non-burn Resistor, RMC73: Chip Resistor, RE: Standing
Resistor, FR: Fuse Resistor
Semiconductor ...... TR:Transistor, DI:Diode, ZD:Zener diode, VA:Varistor, TH:Thermistor, IC:IC.
C53 0890081R CER CAP B 330PF 50V K [E, EBS]
C53 0890085R
CER CAP B 680PF 50V K [W, WUN , WAU]
C54 0890081R CER CAP B 330PF 50V K [E, EBS]
C54 0890085R
CER CAP B 680PF 50V [W, WUN, WAU]
C55 0890075R CER CAP SL 120PF 50V J [E, EBS]
C56 0890101R CER CAP B 10000PF 16V K
C57 0890101R CER CAP B 10000PF 16V K
C59 0890101R CER CAP B 10000PF 16V K
C60 0890101R CER CAP B 10000PF 16V K
C61 0890096R CER CAP B 4700PF 25V K [E, EBS]
C62 0890096R CER CAP B 4700PF 25V K [E, EBS]
C65 0890101R CER CAP B 10000PF 16V K
C66 0800018Y ELECT CAP SSL 10µF 50V
C67 0890101R CER CAP B 10000PF 16V K
C71 0893211R CHIP CAP X 1500PF
C72 0893211R CHIP CAP X 1500PF
C87 0800018Y ELECT CAP SSL 10µF 50V
C91 0800005Y ELECT CAP SSL 2.2µF 50V [E, EBS]
C92 0890084R CER CAP B 560PF 50V K [E, EBS]
C93 0890101R CER CAP B 10000PF 16V K [E, EBS]
C94 0800018Y ELECT CAP SSL 10µF 50V [E, EBS]
C95 0890119R CER CAP CH 27PF 50V J [E, EBS]
C96 0890119R CER CAP CH 27PF 50V J [E, EBS]
C97 0800018Y ELECT CAP SSL 10µF 50V [E, EBS]
C101 0893131R CHIP CAP 39CH 220PF J 50V
C102 0893131R CHIP CAP 39CH 220PF J 50V
C103 0800018Y ELECT CAP SSL 10µF 50V
C104 0800018Y ELECT CAP SSL 10µF 50V
C105 0893126R CHIP CAP 39CH 100PF J 50V
C106 0893126R CHIP CAP 39CH 100PF J 50V
C107 0800034Y ELECT CAP SSL 33µF 35V
C108 0800034Y ELECT CAP SSL 33µF 35V
C109 0880041R MYLAR CAP 0.0056µF K 50V
C110 0880041R MYLAR CAP 0.0056µF K 50V
C111 0880004R MYLAR CAP 0.0015µF K 50V AMZ T
C112 0880004R MYLAR CAP 0.0015µF K 50V AMZ T
C113 0800005Y ELECT CAP SSL 2.2µF 50V
C114 0800005Y ELECT CAP SSL 2.2µF 50V
C115 0893239R CHIP CAP 39F 10000PF Z 50V
C116 0893239R CHIP CAP 39F 10000PF Z 50V
C117 0800003Y ELECT CAP SSL 1µF 50V
C121 0893133R CHIP CAP 39CH 330PF J 50V [E, EBS]
C122 0893133R CHIP CAP 39CH 330PF J 50V [E, EBS]
C123 0893133R CHIP CAP 39CH 330PF J 50V [E, EBS]
C124 0893133R CHIP CAP 39CH 330PF J 50V [E, EBS]
C125 0893133R CHIP CAP 39CH 330PF J 50V [E, EBS]
C126 0893133R CHIP CAP 39CH 330PF J 50V [E, EBS]
C1 0890101R CER.CAP B 10000PF 16V K
C3 0890118R CER CAP CH 22PF 50V J
C4 0890062R CER CAP SL 12PF 50V J
C5 0800042Y ELECT CAP SSL 47µF 25V
C6 0890101R CER CAP B 10000PF 16V K
C7 0890101R CER CAP B 10000PF 16V K
C8 0890074R CER CAP SL 100PF 50V J
C9 H240068 AXIAL-CAP F 100000PF Z 50V
C11 0284623R ELECT CAP SME(BP) 1µF 50V
C12 0800003Y ELECT CAP SSL 1µF 50V
C13 0800042Y ELECT CAP SSL 47µF 25V
C15 0890101R CER CAP B 10000PF 16V K
C16 0890074R CER CAP SL 100PF 50V J
C17 0890074R CER CAP SL 100PF 50V J
C18 0890101R CER CAP B 10000PF 16V K
C19 0800001Y ELECT CAP SSL 0.47µF 50V
C20 0800003Y ELECT CAP SSL 1µF 50V
C21 0800018Y ELECT CAP SSL 10µF 50V
C22 0890102R CER CAP F 22000PF 50V Z
C23 0890074R
CER CAP SL 100PF 50V J [W, WUN,WAU]
C24 0880054R CAP POLY FILM 0.056µF K 50V
C25 0800026Y ELECT CAP SSL 22µF 50V
C26 0800026Y ELECT CAP SSL 22µF 50V [E, EBS]
C27 0800026Y ELECT CAP SSL 22µF 50V
C28 0800333R ELECT CAP SMG 220µF 6.3V
C29 0890101R CER CAP B 10000PF 16V K
C30 0890084R CER CAP B 560PF 50V K [E, EBS]
C31 0890101R CER CAP B 10000PF 16V K
C33 0890116R CER CAP CH 15PF 50V J
C34 0890116R CER CAP CH 15PF 50V J
C36 0890101R CER CAP B 10000PF 16V K
C37 0890101R CER CAP B 10000PF 16V K
C38 0880014R MYLAR CAP 0.047µF K 50V AMZ T
C39 0890102R CER CAP F 22000PF 50V Z
C40 0800001Y ELECT CAP SSL 0.47µF 50V
C41 0800042Y ELECT CAP SSL 47µF 25V
C42 0800003Y ELECT CAP SSL 1µF 50V
C43 0800103R ELECT CAP SRA 0.22µF 50V
C44 0800003Y ELECT CAP SSL 1µF 50V
C45 0890101R CER CAP B 10000PF 16V K
C46 0800005Y ELECT CAP SSL 2.2µF 50V
C47 0800005Y ELECT CAP SSL 2.2µF 50V
C48 0800003Y ELECT CAP SSL 1µF 50V
C49 0890101R CER CAP B 10000PF 16V K
C51 0800005Y ELECT CAP SSL 2.2µF 50V
C52 0800018Y ELECT CAP SSL 10µF 50V
DESCRIPTION
SYMBOL
NO.
PART NO. DESCRIPTIONPART NO.
SYMBOL
NO.
CAPACITORS:
