HTA-DD3
 3 
SPECIFICATIONS
 AUDIO SECTION
(Power amplifier) For (E, EBS) For (W, WUN, WAU)
Rated output: Front: 80 W + 80 W (6 Ω/ohms, 20 Hz ~ 20 kHz with 0.1 % T.H.D.) 100 W + 100 W (EIAJ, 6 ohms)
Centre: 80 W (6 Ω/ohms, 20 Hz ~ 20 kHz with 0.1 % T.H.D.) 100 W (EIAJ, 6 ohms)
Surround: 80 W + 80 W (6 Ω/ohms, 20 Hz ~ 20 kHz with 0.1 % T.H.D.) 100 W + 100 W (EIAJ, 6 ohms)
SINUS power: Front: 90 W + 90 W (6 Ω/ohms, 1 kHz, 0.1 %)
Centre: 90 W (6 Ω/ohms, 1 kHz, 0.1 %)
Surround: 90 W + 90 W (6 Ω/ohms, 1 kHz, 0.1 %)
Output terminals: Front: A or B 6 to 16 Ω/ohms
A + B 12 Ω/ohms or more
Center/Surround: 6 to 16 Ω/ohms
(Analog)
LINE input
Input sensitivity / input impedance: 200 mV / 47 kΩ/kohms
Frequency response: 10 Hz ~ 50 kHz: +1, 3 dB
S/N ratio: 93 dB (IHF-A weighted)
Total harmonic distortion: 0.1% (20 Hz ~ 20 kHz)
PHONO input-REC OUT
Input sensitivity / input impedance: 2.5 mV / 47 kΩ/kohms
RIAA deviation: ±1 dB (20 Hz ~ 20 kHz)
S/N ratio: 74 dB (IHF-A weighted, with 5mV input)
Total harmonic distortion: 0.03% (1 kHz, 3V)
Rated output / Maximum output: 150 mV / 7V
•VIDEO SECTION
(Composite)
Input/output level and impedance: 1 Vp-p, 75 Ω/ohms
Frequency response: 5 Hz ~ 10 MHz +1, 3 dB
(S-Video)
Input/output level and impedance: Y=1 Vp-p, C=0.286 Vp-p
Frequency response: 5 Hz ~ 10 MHz +1, 3 dB
(Component)
Input/output level and impedance: Y=1 Vp-p, C
B
=0.7 Vp-p, C
R
=0.7 Vp-p
Frequency response: 5 Hz ~ 10 MHz +1, 3 dB
•TUNER SECTION
[FM] (note: µV at 75Ω/ohms, 0 dBF = 1 ∞ 10
-15
W) [AM]
Receiving range: 87.50 MHz ~ 108.00 MHz (0.05 MHz step) 522 kHz ~ 1611 kHz (9 kHz step) (E, EBS)
522 kHz ~ 1611kHz (9 kHz step),
520 ~ 1710 kHz (10 kHz step) (W, WUN,WAU)
Usable sensitivity: 2.0 µV (17.2 dBf) 600 µV
50 dB quieting sensitivity: STEREO 23µV (38.5 dBf)
S/N ratio: MONO 80 dB (IHF-A weighted)
STEREO 75 dB (IHF-A weighted)
Total harmonic distortion: MONO 0.2% (1kHz)
STEREO 0.4% (1kHz)
• GENERAL
Power supply: AC 230V, 50 Hz (E,EBS), AC 110 ~ 127V/220 ~ 240V, 50/60 Hz (W, WUN,WAU)
Power consumption: 180 W (Standby mode = 1.5W)
Maximum external dimensions: 434 (W) ∞ 144 (H) ∞ 320 (D) mm
Weight: 8.1 kg
• REMOTE CONTROL UNIT (RB-DD1S)
Batteries: R6P/AA Type (two batteries)
External dimensions: 54 (W) ∞ 172 (H) ∞ 27.2 (D) mm
Weight: 100 g (including batteries)
• Accessory supplied: Operating instructions, Remote control unit (RB-DD1S),
R6P/AA batteries, AM loop antenna and FM indoor antenna
* For purposes of improvement, specifications and design are subject to change without notice.
