 61 
HTA-DD3
PRODUCT SAFETY NOTE: Components marked with a have special characteristics important to safety. Before replacing any of these
components, please read carefully the Service Manual.
DESCRIPTION
SYMBOL
NO.
PART NO.
DESCRIPTIONPART NO.
SYMBOL
NO.
PG3 2658692W TXL-P03P-M1 (RIGHT ANGLE)
PG12 2959053 PIN POST (A2001WV2-4P)
PG13 2959056 PIN POST (A2001WV2-7P)
PG14 2959051 2P PIN POST (A2001WV2-2P)
PG15 2959052 PIN POST (A2001WV2-3P)
PG22 2959051 2P PIN POST (A2001WV2-2P)
PG24 2959052 3P PH PIN POST
PG25 2674284 3.96MM PIN POST (B2P4-VH-B)
PG205 2674264 MX MINI PIN POST (53253-0510)
PG206 2674262 MX MINI PIN POST (53253-0310)
RY401 2641322 SPEAKER RELAY ALA2F24
RY402 2641322 SPEAKER RELAY ALA2F24
RY501 2641322 SPEAKER RELAY ALA2F24
RY502 2641322 SPEAKER RELAY ALA2F24
RY503 2641322 SPEAKER RELAY ALA2F24
RY901 FJ00152 RELAY (ALKS325)
T201 0544408 LUG TERMINAL
TH801 CJ00151 THERMISTOR PTH9M04BB
TU1 HH00041 TUNER PACK [W, WUN, WAU]
TU1 HH00042 TUNER PACK FE450-G01[E, EBS]
VR1 AW00107 VAR RES NVZ6TL1 B20K
VR752 AY00682 VAR RES 30K-C XVB141 02GPVN17
VR753 AY00681 VAR RES 10K-C XVB141 GPVN17.5
W1 EK01218 1P BOARD IN CONN L=100MM WHT
[W, WUN, WAU]
W2 EK01236 1P BOARD IN CONN L=150MM BLUE
[W, WUN WAU]
W3 EK01231 1P BOARD IN CONN L=150MM BLK
[W, WUN, WAU]
W4 EK01231 1P BOARD IN CONN L=150MM BLK
W5 EK01244 1P BOARD IN CONN L=175MM ORG
W6 EK01244 1P BOARD IN CONN L=175MM ORG
[W, WUN, WAU]
W7 EK01233 1P BOARD IN CONN L=150MM RED
[W, WUN, WAU]
W8 EK01246 1P BOARD IN CONN L=175MM BLU
[W, WUN, WAU]
W9 EK01241 1P BOARD IN CONN L=175MM BLK
[W, WUN, WAU]
W251 EK00234 HCUJ (1.25)-7F-90-10S5
W261 EK01023 19P FFC CABLE (L=130)
X801 BP00141 OSC CST8.00MTW
X201 BP01071 CRYSTAL 12.288MHZ
XT1 2170132R CRYSTAL 7.200MHZ TAPING
XT91 2170133R CRYSTAL 4.332MHZ TAPING [E, EBS]
XT92 2792071R CER.OSC.CST4.00MGW-TF01 [E, EBS]
Z017 9563449 NISSEI SF SLEEVE ESG-3 8MM DIA
Z019 1ZA4042 SENJU SOLDER
Z020 9473457 ETHYL ALCOHOL
Z022 9414017 SILICONE GREASE G-746
Z023 9414017 SILICONE GREASE G-746
Z024 7998081 NITTO SPV-367 TAPE 70MMX200M
Z025 9451125 UL TUBE NO.7/16 AH6 CLEAR
1 8679606 SCREW 4X6 DT BIND B
2 8699410 SCREW 3X10 BT BIND B
3 8699410 SCREW 3X10 BT BIND B
4 8699414 SCREW 3X14 BT BIND B
5 8679606 SCREW 4X6 DT BIND B
6 8691410 SCREW 3X10 BT BIND
7 8691414 SCREW 3X14 BT BIND
8 8691410 SCREW 3X10 BT BIND
9 8699408 SCREW 3X8 BT BIND B
10 8699410 SCREW 3X10 BT BIND B
11 8699410 SCREW 3X10 BT BIND B
12 8991410 SCREW 3X10 BT BIND
13 8691410 SCREW 3X10 BT BIND
14 8679406 SCREW 3X6 DT BIND B
15 8679406 SCREW 3X6 DT BIND B
16 8679408 SCREW 3X8 DT BIND B
17 NX03961 PHONO EARTH TERMINAL
18 QJ00214 FOOT (W)
QJ00213 FOOT (E, EBS, WUN, WAU)
19 PC04294 TUNER BUTTON [E, EBS, WUN, WAU]
PC04293 TUNER BUTTON (W)
20 PC04272 MASTER VOL KNOB [E, EBS, WUN,
WAU]
PC04273 MASTER VOL KNOB (W)
21 PC04282 BASS TREBLE KNOB [E, EBS, WUN,
WAU]
PC04283 BASS TREBLE KNOB (W)
22 PH08312 CLEAR PANEL
23 PC01785 POWER BUTTON (W)
PC01784 POWER BUTTON [E, EBS, WUN, WAU]
24 8691408 SCREW 3X8 BT BIND
25 8691410 SCREW 3X10 BT BIND
26 8679406 SCREW 3X6 DT BIND B
27 MS00211 FELT
28 QA02071 TOP COVER [E, EBS, WUN, WAU]
QA00499 TOP COVER (W)
29 QA00481 BOTTOM CHASSIS
30 4692076 CUSHION
31 MN01592 TOP COVER SHEET (W)
MN01593 TOP COVER SHEET [E, EBS, WUN
WAU]
32 NJ02063 SHEET HOLDER [E, EBS, WUN, WAU]
NJ02062 SHEET HOLDER (W)
33 ML00251 MINI PWB POST
34 ML01011 PWB SUPPORT
35 ML00261 PWB SUPPORT L
36 MK00246 NUT M9X0.75
37 MK00321 NUT M12X1
38 EV00586 AC CORD W/BUSH [E, EBS, WUN,
WAU]
EV00589 AC CORD W/BUSH (WAU)
CABINET CHASSIS:
