Hitachi NEXT Series Service Manual

56
Confidential to Customer
■ Connection position on the PCB side
CN2
(From PS4)
CN3
(From TH4)
CN4
(From TH5)
CN13
(From TH3)
CN2
(From TH10)
CN1
(From PS1)
CN16
(From PS2)
CN10
(From TH2)
CN11
(From PS1)
CN13
(From TH3)
CN16
(From PS2)
THM
■ Sensor position for air-cooled type
TH2
TH3
TH4TH5
PS1
PS4 PS2 PS1
PS4
PS2
LCD PCB side
(See the back side of instrument panel.)
CPU PCB side
(control panel side)
[Fixed speed type]
[Fixed speed type]
