Hitachi NV 83A3 - Page 59

Item
No.
Part Name Q’TY
1
HEX. SOCKET HD. BOLT (W/FLANGE) M6 × 45 3
2TOP COVER 1
3
HEX. SOCKET HD. BOLT (W/SP.WASHER)
M6 × 25
4
4EXHAUST COVER 1
5GASKET (B) 1
6GASKET (F) 1
7EXHAUST PIECE 1
8GASKET (C) 1
9EXHAUST VALVE 1
10 HEAD CAP 1
11 O -RING (1AP-48) 1
12 PISTON (H) 1
13 O-RING (S-90) 3
14 CYLINDER O-RING (I.D 63.1) 1
15 CYLINDER PLATE 1
16 CYLINDER O-RING (I.D 79.3) 1
17 CYLINDER 1
18 O-RING (I.D 59.6/W2.4) 1
19 GUIDE SLEEVE 1
20 O-RING (S-70) 1
21 CYLINDER RING 1
22 CYLINDER SPRING 1
23 CYLINDER GUIDE 1
24 WARNING LABEL 1
25 BODY ASS'Y 1
26 LABEL 1
27 CYLINDER O-RING (I.D 63.9) 1
28 PISTON BUMPER (B) 1
29 GASKET (A) 1
30 NOSE 1
31 FEEDER SHAFT RING 1
32 FEEDER SPRING 1
33 FEEDER 1
34 FEEDER SHAFT 1
35 ROLL PIN D3 × 20 1
36 NYLOCK HEX. SOCKET HD. BOLT M8 × 22 4
37 NAIL GUIDE SHAFT 1
38 BASE WASHER 2
39 GASKET (G) 1
40 GRIP RUBBER 1
41 GASKET (D) 1
42 CAP 1
43 HEX. SOCKET HD. BOLT M5 × 18 3
44 AIR PLUG NPT 3/8 1
45 MACHINE SCREW M5 × 25 1
46 MANE PLATER 1
47 VALVE GUARD 1
48 ROLL PIN D3 × 45 1
49 O-RING (S3) 1
50 PUSHING LEVER (B) 1
51 SPRING 1
52 ADJUSTER 1
53 ADJUSTER SPRING 2
54 STEEL BALL D3.175 2
55 WASHER 1
56 HEX. SOCKET HD. BOLT M6 × 12 1
57 PUSHING LEVER (A) 1
58 O-RING (P-9) 1
59 FEED PISTON 1
60 O-RING (P-22) 1
Item
No.
Part Name Q’TY
61 FEED SPRING 1
62 BUMPER 1
63 FEED PISTON COVER (A) 1
64 FEED PISTON COVER 1
65 SEAL LOCK HEX. SOCKET HD. BOLT M5 × 10 2
66 MAGAZINE BUSHING 1
67 NYLON NUT M5 2
68 SLEEVE 1
69 GUARD 1
70 NAIL GUIDE 1
71 ROLL PIN D3 × 10 1
72 GUIDE LOCK (A) 1
73 SPRING 1
74 SPRING 1
75 SHAFT RING 1
76 LOCK SHAFT 1
77 HEX. SOCKET HD. BOLT M5 × 20 1
78 SUB NAIL STOPPER (N) 1
79 SUB STOPPER SPRING 1
80 ROLL PIN D3 × 28 1
81 MAIN NAIL STOPPER (N) 1
82 MAIN STOPPER SPRING 1
83 NAIL GUIDE COVER 1
84 COVER 1
85 PLATE 1
86 SEAL LOCK HEX. SOCKET HD. BOLT M4 × 8 2
87 PLUNGER SPRING 1
88 O-RING (P-4) 1
89 PLUNGER 1
90 O-RING (I.D 10.7) 2
91 VALVE BUSHING 1
92 TRIGGER SPRING 1
93 TRIGGER 1
94 ROD SPRING 1
95 ROD(A) 1
96 CHANGE KNOB 1
97 PIN 1
98 ROLL PIN D3 × 30 1
99 ROD (B) 1
100 ROD (C) 1
101 RATCHET SPRING 1
102 VALVE PACKING 1
103 URETHANE BALL (C) D7.14 1
104 O-RING (S-12) 1
105 VALVE PLATE 1
106 TRIGGER VALVE BUSHING 1
107 O-RING 1
108 TRIGGER PLUNGER 1
109 MAGAZINE 1
110 PIN 2
111 FEEDER SHAFT RING 2
112 MAGAZINE COVER 1
113 HOLDER CAP 1
114 RATCHET SPRING 1
115 NAIL HOLDER (A) 1
116 ROLL PIN D2.5 1
117 HOLDER SHAF T 1
118 SPRING 1
119 MAGAZINE ASS'Y 1
501 PROTECTIVE GLASSES 1
59
