Hitachi nv90ag - Page 2

PART
S
NV 90AG
DESCRIPTION REMARKS
1 949-665 HEX. SOCKET HD. BOLT M5 X 14 (10 PCS.) 4
2 884-952 HEAD GUARD 1
3 886-454 SHEET 1
4 878-877
HEX. SOCKET HD. BOLT (W/FLANGE) M6 X 30 4
5 886-261 EXHAUST COVER 1
6 886-455 GASKET (A) 1
7 886-456 HEAD VALVE SPRING 1
8 884-947 O-RING (I.D 49.4) 1
9 884-946 HEAD VALVE 1
10 884-948 O-RING (I.D 59.4) 1
11 884-950 EXHAUST VALVE RUBBER 1
12 884-945 VALVE RUBBER 1
13 888-032 CYLINDER 1
14 884-944 CYLINDER PLATE 1
15 886-481 O-RING (I.D 94.6) 1
16 886-480 O-RING (I.D 59.6) 1
17 886-483 CYLINDER RING 1
18 888-033 PISTON 1
19 884-958 PISTON O-RING 1
20 887-668 CHANGE ROD (D) 1
21 888-116 BODY ASS'Y 1 INCLUD. 38, 40
* 22 883-513 WARNING LABEL (A) 1 FOR EUROPE
23 NAME PLATE 1
24 886-356 HITACHI LABEL 1
25 888-100 PISTON BUMPER 1
26 886-482 O-RING (I.D 60) 1
27 874-436 O-RING (P-4) 2
28 888-101 WASHER 1
29 888-034 NOSE 1
30 949-497 ROLL PIN D4 X 16 (10 PCS.) 1
31 888-043 NEEDLE ROLLER 1
32 306-437 NYLOCK HEX. SOCKET HD. BOLT M8 X 30 4
33 878-132 FEEDER ARM 1
34 888-108 FEEDER SPRING 1
35 888-042 FEEDER 1
36 887-847 NAIL GUIDE SHAFT 1
37 888-046 PUSHING LEVER (A) 1
38 886-260 GRIP RUBBER (B) 1
39 963-837 NYLON NUT M6 1
40 GRIP RUBBER (A) 1 SUPPLIED WITH ITEM NO. 601, 602
41 884-342 GASKET (B) 1
42 881-949 CAP 1
43 949-821 HEX. SOCKET HD. BOLT M5 X 16 (10 PCS.) 3
44 887-863 AIR PLUG NPT 3/8 1
45 877-763 FEED PISTON O-RING (I.D. 14) 1
46 884-963 VALVE BUSHING (B) 1
47 873-570 O-RING (P-18) 1
48 884-964 VALVE PISTON 1
49 872-654 O-RING (1AP-10) 1
50 887-178 PLUNGER SPRING 1
- 2 - 1 - 13
*ALTERNATIVE PARTS
ITEM
NO.
NO.
USED
CODE NO.
ITEM
NO.
NO.
USED
CODE NO.
