IEC 61850 or
function name
ANSI Function description Line Differential
RED670
(Customized)
RED670 (B33)
RED670 (A42)
RED670 (B42)
RED670 (C42)
LOCREMCTRL LHMI control of PSTO 1 1 1 1 1
SXCBR Circuit breaker 6 6 3 6 3
SLGAPC Logic rotating switch for
function selection and LHMI
presentation
15 15 15 15 15
VSGAPC Selector mini switch 30 30 30 30 30
DPGAPC Generic communication
function for Double Point
indication
32 32 32 32 32
SPC8GAPC Single point generic control
function, 8 signals
5 5 5 5 5
AUTOBITS Automation bits, command
function for DNP3.0
3 3 3 3 3
SINGLECMD Single command, 16 signals 8 8 8 8 8
I103CMD Function commands for IEC
60870-5-103
1 1 1 1 1
I103GENCMD Function commands generic
for IEC 60870-5-103
50 50 50 50 50
I103POSCMD IED commands with position
and select for IEC
60870-5-103
50 50 50 50 50
I103POSCMDV IED direct commands with
position for IEC 60870-5-103
50 50 50 50 50
I103IEDCMD IED commands for IEC
60870-5-103
1 1 1 1 1
I103USRCMD Function commands user
defined for IEC 60870-5-103
4 4 4 4 4
Secondary system supervision
CCSSPVC 87 Current circuit supervision 0-2 2 1 2 1
FUFSPVC Fuse failure supervision 0-3 3 3 3 3
VDSPVC 60 Fuse failure supervision based
on voltage difference
0-2 1-G03 1-G03 1-G03 1-G03
DELVSPVC 7V_78V Voltage delta supervision 4 4 4 4 4
DELISPVC 7I Current delta supervision 4 4 4 4 4
DELSPVC 78 Real delta supervision, real 4 4 4 4 4
Logic
SMPPTRC 94 Tripping logic 12 12 12 12 12
SMAGAPC General start matrix block 12 12 12 12 12
STARTCOMB Start combinator 32 32 32 32 32
TMAGAPC Trip matrix logic 12 12 12 12 12
ALMCALH Logic for group alarm 5 5 5 5 5
WRNCALH Logic for group warning 5 5 5 5 5
INDCALH Logic for group indication 5 5 5 5 5
