Table 7: Total number of instances for extended logic package
Extended configurable logic block Total number of instances
AND 220
GATE 49
INV 220
LLD 49
OR 220
PULSETIMER 89
RSMEMORY 40
SLGAPC 74
SRMEMORY 130
TIMERSET 113
VSGAPC 120
XOR 89
3.4 Communication
GUID-C1FB7B84-2F43-4F15-9264-F33832C8036B v1
IEC 61850 or function
name
ANSI Function description Line Differential
RED670
(Customized)
RED670 (B33) RED670 (A42) RED670 (B42) RED670 (C42)
Station communication
LONSPA, SPA SPA communication
protocol
1 1 1 1 1
ADE LON communication
protocol
1 1 1 1 1
HORZCOMM Network variables via LON 1 1 1 1 1
PROTOCOL Operation selection
between SPA and IEC
60870-5-103 for SLM
1 1 1 1 1
RS485PROT Operation selection for
RS485
1 1 1 1 1
RS485GEN RS485 1 1 1 1 1
DNPGEN DNP3.0 communication
general protocol
1 1 1 1 1
CHSERRS485 DNP3.0 for EIA-485
communication protocol
1 1 1 1 1
CH1TCP, CH2TCP,
CH3TCP, CH4TCP
DNP3.0 for TCP/IP
communication protocol
1 1 1 1 1
CHSEROPT DNP3.0 for TCP/IP and
EIA-485 communication
protocol
1 1 1 1 1
MSTSER DNP3.0 serial master 1 1 1 1 1
MST1TCP,
MST2TCP,
MST3TCP, MST4TCP
DNP3.0 for TCP/IP
communication protocol
1 1 1 1 1
Table continues on next page
