IEC 61850 or function
name
ANSI Function description Line Differential
RED670
(Customized)
RED670 (B33) RED670 (A42) RED670 (B42) RED670 (C42)
DNPFREC DNP3.0 fault records for
TCP/IP and EIA-485
communication protocol
1 1 1 1 1
IEC 61850-8-1 IEC 61850 1 1 1 1 1
GOOSEINTLKRCV Horizontal communication
via GOOSE for interlocking
59 59 59 59 59
IEC 61850SIM IEC 61850 simulation
mode
1 1 1 1 1
GOOSEBINRCV GOOSE binary receive 16 16 16 16 16
GOOSEDPRCV GOOSE function block to
receive a double point
value
64 64 64 64 64
GOOSEINTRCV GOOSE function block to
receive an integer value
32 32 32 32 32
GOOSEMVRCV GOOSE function block to
receive a measurand value
60 60 60 60 60
GOOSESPRCV GOOSE function block to
receive a single point
value
64 64 64 64 64
ALGOS Supervision of GOOSE
subscription
100 100 100 100 100
MULTICMDRCV,
MULTICMDSND
Multiple command and
transmit
60/10 60/10 60/10 60/10 60/10
OPTICAL103 IEC 60870-5-103 Optical
serial communication
1 1 1 1 1
RS485103 IEC 60870-5-103 serial
communication for RS485
1 1 1 1 1
AGSAL Generic security
application component
1 1 1 1 1
LD0LLN0 IEC 61850 LD0 LLN0 1 1 1 1 1
SYSLLN0 IEC 61850 SYS LLN0 1 1 1 1 1
LPHD Physical device
information
1 1 1 1 1
PCMACCS IED configuration protocol 1 1 1 1 1
SECALARM Component for mapping
security events on
protocols such as DNP3
and IEC103
1 1 1 1 1
FSTACCSNA Field service tool access
via SPA protocol over
Ethernet communication
1 1 1 1 1
FSTACCS Field service tool access 1 1 1 1 1
IEC 61850-9-2 Process
bus communication, 8
merging units
0-1 1-P30 1-P30 1-P30 1-P30
ACTIVLOG Activity logging 1 1 1 1 1
Table continues on next page
Section 3 1MRK 505 378-UEN Rev. K
Available functions
38 Line differential protection RED670
Commissioning manual
