IEC 61850 or function
name
ANSI Function description Line Differential
RED670
(Customized)
RED670 (B33) RED670 (A42) RED670 (B42) RED670 (C42)
ALTRK Service tracking 1 1 1 1 1
PRP IEC 62439-3 Parallel
redundancy protocol
0-1 1-P23 1-P23 1-P23 1-P23
HSR IEC 62439-3 High-
availability seamless
redundancy
0-1 1-P24 1-P24 1-P24 1-P24
RSTP IEC 62439-3 Rapid
spanning tree protocol
0-1 1-P25 1-P25 1-P25 1-P25
PMUCONF,
PMUREPORT,
PHASORREPORT1,
ANALOGREPORT1,
BINARYREPORT1,
SMAI1 - SMAI12,
3PHSUM,
PMUSTATUS
Synchrophasor report, 8
phasors (see Table 9)
0-1 1-P32 1-P32 1-P32 1-P32
AP_1-AP_6 AccessPoint_ABS 1 1 1 1 1
AP_FRONT Access point front 1 1 1 1 1
PTP Precision time protocol 1 1 1 1 1
ROUTE_1-ROUTE_6 Route_ABS1-Route_ABS6 1 1 1 1 1
FRONTSTATUS Access point diagnostic for
front Ethernet port
1 1 1 1 1
SCHLCCH Access point diagnostic for
non-redundant Ethernet
port
6 6 6 6 6
RCHLCCH Access point diagnostic for
redundant Ethernet ports
3 3 3 3 3
DHCP DHCP configuration for
front access point
1 1 1 1 1
QUALEXP IEC 61850 quality
expander
96 96 96 96 96
Remote communication
BinSignRec1_1
BinSignRec1_2
BinSignReceive2
Binary signal transfer,
receive
3/3/6 3/3/6 3/3/6 3/3/6 3/3/6
BinSignTrans1_1
BinSignTrans1_2
BinSignTransm2
Binary signal transfer,
transmit
3/3/6 3/3/6 3/3/6 3/3/6 3/3/6
BSR2M_305
BSR2M_312
BSR2M_322
BSR2M_306
BSR2M_313
BSR2M_323
Binary signal transfer,
2Mbit receive
1 1 1 1 1
Table continues on next page
