IEC 61850 or
function name
ANSI Function description Line Differential
RED670
(Customized)
RED670 (B33) RED670 (A42) RED670 (B42) RED670 (C42)
POL_REC Polar to rectangular converter 20 20 20 20 20
RAD_DEG Radians to degree angle
converter
20 20 20 20 20
CONST_REAL Definable constant for logic
functions
10 10 10 10 10
REALSEL Analog input selctor for real
values
5 5 5 5 5
STOREINT Store value for integer inputs 10 10 10 10 10
STOREREAL Store value for real inputs 10 10 10 10 10
DEG_RAD Degree to radians angle
converter
20 20 20 20 20
Monitoring
CVMMXN Power system measurement 6 6 6 6 6
CMMXU Current measurement 10 10 10 10 10
VMMXU Voltage measurement phase-
phase
6 6 6 6 6
CMSQI Current sequence
measurement
6 6 6 6 6
VMSQI Voltage sequence
measurement
6 6 6 6 6
VNMMXU Voltage measurement phase-
earth
6 6 6 6 6
AISVBAS General service value
presentation of analog inputs
1 1 1 1 1
EVENT Event function 20 20 20 20 20
DRPRDRE,
A1RADR-
A4RADR,
B1RBDR-
B22RBDR
Disturbance report 1 1 1 1 1
SPGAPC Generic communication
function for single point
indication
96 96 96 96 96
SP16GAPC Generic communication
function for single point
indication, 16 inputs
16 16 16 16 16
MVGAPC Generic communication
function for measured values
60 60 60 60 60
BINSTATREP Logical signal status report 3 3 3 3 3
RANGE_XP Measured value expander
block
66 66 66 66 66
SSIMG 63 Insulation supervision for gas
medium
21 21 21 21 21
SSIML 71 Insulation supervision for
liquid medium
3 3 3 3 3
Table continues on next page
1MRK 505 378-UEN Rev. K Section 3
Available functions
Line differential protection RED670 33
Commissioning manual
