4-13
Chapter 4
Safety Function
No.
Name
Range
Default
Memo
1-11
Keep Time after STO-A
0.00 to 3600.00s
1.00
1-12
STO-A release mode
00:without release / 01:with safety signal /
02:with release signal
01
1-21
SS1-A Zero frequency
0.10 to 10.00Hz
5.00
1-22
SS1-A monitoring method
00:Time /01: Frequency
00
1-23
SS1-A Active time
0.00 to 3600.00s
1.00
1-24
SS1-A Min ramp time
0.00 to 3600.00s
1.00
1-25
SS1-A Max ramp time
0.00 to 3960.00s
30.00
1-26
SS1-A Wait Time
0.00 to 600.00s
1.00
1-31
SBC-A Time linkage
00: SBC after STO/01: SBC before STO/
02:SS1 then SBC after STO/03:SS1 then SBC before STO
00
1-32
SBC-A Wait time after STO-A
0.00 to 3600.00s
1.00
1-33
SBC-A Wait time before STO-A
0.00 to 10.00s
1.00
1-34
SBC-A frequency
0.00 to 100.00Hz
0.00
1-35
SBC-A STO-A release wait time
0.00 to 10.00s
0.00
1-36
SBC-A release level
0.00 to 100.00%
100.00
1-41
SLS-A frequency limit CCW/FW
0.00 to 590.00Hz
72.00
1-42
SLS-A frequency limit CW/RV
0.00 to 590.00Hz
50.00
1-43
SLS-A time delay
0.00 to 3600.00s
10.00
1-51
SDI-A active mode
00:CW(RV)-limit/01:CCW(FW)-limit
00
1-52
SDI-A time delay
0.00 to 3600.00s
10.00
1-61
SSM-A frequency CCW/FW
0.00 to 590.00Hz
72.00
1-62
SSM-A frequency CW/RV
0.00 to 590.00Hz
50.00
2-11
Keep Time after STO-B
0.00 to 3600.00s
1.00
2-12
STO-B release mode
00:without release / 01:with safety signal /
02:with release signal
01
2-21
SS1-B Zero frequency
0.10 to 10.00Hz
5.00
2-22
SS1-B monitoring method
00:Time /01: frequency
00
2-23
SS1-B Active time
0.00 to 3600.00s
1.00
2-24
SS1-B Min ramp time
0.00 to 3600.00s
1.00
2-25
SS1-B Max ramp time
0.00 to 3960.00s
30.00
2-26
SS1-B Wait Time
0.00 to 600.00s
1.00
2-31
SBC-B Time linkage
00: SBC after STO/01: SBC before STO/
02:SS1 then SBC after STO/03:SS1 then SBC before STO
00
2-32
SBC-B Wait time after STO-B
0.00 to 3600.00s
1.00
2-33
SBC-B Wait time before STO-B
0.00 to 10.00s
1.00
2-34
SBC-B frequency
0.00 to 100.00Hz
0.00
2-35
SBC-B STO-B release wait time
0.00 to 10.00s
0.00
2-36
SBC-B release level
0.00 to 100.00%
100.00
2-41
SLS-B frequency limit CCW/FW
0.00 to 590.00Hz
72.00
2-42
SLS-B frequency limit CW/RV
0.00 to 590.00Hz
50.00
2-43
SLS-B time delay
0.00 to 3600.00s
10.00
2-51
SDI-B active mode
00:CW(RV)-limit/01:CCW(FW)-limit
00
2-52
SDI-B time delay
0.00 to 3600.00s
10.00
2-61
SSM-B frequency CCW/FW
0.00 to 590.00Hz
72.00
2-62
SSM-B frequency CW/RV
0.00 to 590.00Hz
50.00
