S-2
S.3 Relevant document
S.4 List of abbreviation and
technical terms
A
American wire gauge
Standardized wire gauge used in
North America
B
The documentation that
provides basic information to
handle the inverter
C
Category
Structural Classification of the
safety-related parts defined in
EN ISO13849-1 (B,1,2,3,4)
Common Cause Failure (EN ISO
13849-1)
Failure, which is the result of
one or more events, causing
concurrent failure of two or
more separate channels in a
multiple channel system,
leading to failure of the Safety
function
A mandatory conformity
marking for products sold
within the European Economic
Area.
The lamp indicates power
supply status of the main circuit
of the inverter. Even after
powered down, the internal
voltage remains while the lamp
lights.
Internal power supply
necessary for powering up the
logic board and configuring the
inverter using operator keypad.
Supplying power to R0T0
terminal or P+, P- terminal can
power up the internal power
supply.
*) Trademark
Some proper nouns such as product name or function
names may be registered as trademark or registered
trademark. Particularly this documentation does not
describes ® mark or
TM
mark.
C
In a redundant system,
multiple channels can be
simultaneously faulted by
certain factors.
D
Failure of a component and/or
subsystem and/or system that
plays a part in implementing
the Safety function
Diagnostic coverage (%) (EN
ISO 13849-1)
E
Electromagnetic compatibility
F
Reduce the risk of harm to an
acceptable level via design
changes or by applying
appropriate safety measures
H
Hardware fault tolerance
(IEC61508)
I
Insulated gate bipolar
transistor
The model code written on the
specification label of the
inverter.
SJ Series P1 User’s Guide
SJ Series P1 Safety Function Guide
SJ Series P1 Safety Function Guide Supplement
P1-FS Safety Function Guide (this documentation)
P1-FS Safety Function Guide Supplement
