Hitachi SJ100 Series - Page 103

SJ100 Inverter
Configuring
Drive Parameters
3–37
H05 Motor constant Kp Motor proportional gain
constant (factory set),
range is 0 to 99
✘ 20 —
F-05 AUX Kp
H205 Motor constant Kp,
2nd motor
Motor proportional gain
constant (factory set)
range is 0 to 99
✘ 20 —
F-05 2AUX
Kp
H06 Motor stabilization
constant
Motor constant (factory set),
range is 0 to 255
✘ 100 —
F-05 AUX
KCD
H206 Motor stabilization
constant, 2nd motor
Motor constant (factory set),
range is 0 to 255
✘ 100 —
F-05 2AUX
KCD
H20 Motor constant R1 Range is 0.000 to 65.53,
0.000 to 9.999
10.00 to 65.53
✘
factory
set
Ohms
F-05 AUX R1
H220 Motor constant R1,
2nd motor
Range is 0.000 to 65.53,
0.000 to 9.999
10.00 to 65.53
✘
factory
set
Ohms
F-05 2AUX
R1
H21 Motor constant R2 Range is 0.000 to 65.53,
0.000 to 9.999
10.00 to 65.53
✘
factory
set
Ohms
F-05 AUX R2
H221 Motor constant R2,
2nd motor
Range is 0.000 to 65.53,
0.000 to 9.999
10.00 to 65.53
✘
factory
set
Ohms
F-05 2AUX
R2
H22 Motor constant L Range is 0.00 - 655.3 mH,
0.00 to 99.99
100.0 - 655.3
✘
factory
set
mH
F-05 AUX L
H222 Motor constant L,
2nd motor
Range is 0.00 - 655.3 mH,
0.00 to 99.99
100.0 - 655.3
✘
factory
set
mH
F-05 2AUX L
H23 Motor constant Io Range is 0.00 to 655.3 Amps,
0.00 to 99.99
100.0 - 655.3
✘
factory
set
Arms
F-05 AUX IO
H223 Motor constant Io,
2nd motor
Range is 0.00 to 655.3 Amps,
0.00 to 99.99
100.0 - 655.3
✘
factory
set
Arms
F-05 2AUX IO
H24 Motor Constant J Ratio (unit-less), range is
1.0 to 1000
✘
factory
set
—
F-05 AUX J
H224 Motor constant J,
2nd motor
Ratio (unit-less), range is
1.0 to 1000
✘
factory
set
—
F-05 2AUX J
H30 Motor constant R1 Auto-tuning data (do not edit) ✘
factory
set
—— —
H230 Motor constant R1,
2nd motor
Auto-tuning data (do not edit) ✘
factory
set
—— —
“H” Function
Run-
time
Edit
Defaults DOP,DRW,DOP+
Func.
Code
Name Description
EU/
US
Units
Func.
Code
Name
