SJ100 Inverter
Operations
and Monitoring
4–35
Parameters for the second motor have a function code of the form x2xx. They appear
immediately after the first motor’s parameter in the menu listing order. The following
table lists the parameters which have the second parameter register for programming.
Function Name
Parameter Codes
1st motor 2nd motor
Multi-speed frequency setting A20 A220
Acceleration time setting (Acceleration 1) F02 F202
Deceleration time setting (Deceleration 1) F03 F203
Second acceleration time setting (Acceleration 2) A92 A292
Second deceleration time setting (Deceleration 2) A93 A293
Select method to use 2nd acceleration/deceleration A94 A294
Acc1 to Acc2 frequency transition point A95 A295
Dec1 to Dec2 frequency transition point A96 A296
Level of electronic thermal setting B12 B212
Select electronic thermal characteristic B13 B213
Torque boost method selection A41 A241
Manual torque boost value A42 A242
Manual torque boost frequency adjustment A43 A243
V/F characteristic curve selection A44 A244
Base frequency setting A03 A203
Maximum frequency setting A04 A204
Select motor constant H02 H202
Motor capacity setting H03 H203
Motor poles setting H04 H204
Motor constant R1 setting (Standard, Auto tuning) H20/H30 H220/H230
Motor constant R2 setting (Standard, Auto tuning) H21/H31 H221/H231
Motor constant L setting (Standard, Auto tuning) H22/H32 H222/H232
Motor constant Io setting (Standard, Auto tuning) H23/H33 H223/H233
Motor constant J setting (Standard, Auto tuning) H24/H34 H224/H234
Motor constant Kp setting (Standard, Auto tuning) H05 H205
Motor stabilization constant H06 H206
