SJ100 Inverter
xv
Revisions
Revision History Table
No. Revision Comments Date of Issue
Operation
Manual No.
Initial release of manual NB583X April 1999 NB583X
1 Revision A
Added 7.5 and 10 HP models to tables and drawings in
Chapters 1 and 2, made minor typographical or technical
corrections throughout manual
May 1999 NB583XA
2 Revision B
Pages 1-4, 5 – Specs tables: corrected weights (lbs), added
row for input current, corrected dynamic braking % torque
Page 2-11 – Added note about fans at bottom of page
Page 2-15 – Added torque specs for 7.5 and 10 HP models
Page 3-36 – Added larger motor sizes to H03/H203 motor
capacity settings in table
Page 3-41 – Added note about SLV operation at top of page
Pages 4-30, 31 – Changed text in notes for Steps 1, 2, and
10 in table to clarify auto-tuning procedure
Pages 4-31, 32 – Added auto-tuning notes at bottom of 4-31
and new page 4-32 about motor parameters, frame size, etc.
Page 5-5 – Added braking resistor specs for 7.5 and 10 HP
models
August 1999 NB583XB
