Footnotes for the preceding tables and the table on the following page:
*1: The protection method conforms to JEM 1030.
*2: The applicable motor refers to Hitachi standard 3-phase motor (4-pole). To use other
motors, care must be taken to prevent the rated motor current (50/60 Hz) from exceeding the
rated output current of the inverter.
*3: The output voltage decreases as the main supply voltage decreases (except for use of the
AVR function). In any case, the output voltage cannot exceed the input power supply
voltage.
*4: To operate the motor beyond 50/60 Hz, consult the motor manufacturer about the maximum
allowable rotation speed.
*5: SLV selected, set carrier frequency more than 2.1 kHz.
*6: At the rated voltage when using a Hitachi standard 3-phase, 4-pole motor (when selecting
high starting torque flux vector control).
*7: The braking torque via capacitive feedback is the average deceleration torque at the shortest
deceleration (stopping from 50/60 Hz as indicated). It is not continuous regenerative braking
torque. And, the average deceleration torque varies with motor loss. This value decreases
when operating beyond 50 Hz. If a large regenerative torque is required, the optional regen-
erative braking resistor should be used.
*8: The frequency command is the maximum frequency at 9.8V for input voltage 0 to 10 VDC,
or at 19.6 mA for input current 4 to 20 mA. If this characteristic is not convenient for your
application, contact your Hitachi sales representative.
*9: If operating the inverter at 40 to 50
°
C, reduce the carrier frequency to 2.1 kHz, derate the
output current by 80%, and remove the top housing cover. Note that removing the top cover
will nullify the NEMA rating for the inverter housing.
*10:The storage temperature refers to the short-term temperature during transport.
*11:Conforms to the test method specified in JIS C0911 (1984). For the model types excluded in
the standard specifications, contact your Hitachi sales representative.
*12:The input voltage of xxLFU is 230V.
Item 400V Class Specifications
SJ100 inverters, 400V models
004HFE
004HFU
007HFE
007HFU
015HFE
015HFU
022HFE
022HFU
030HFE
—
040HFE
040HFU
055HFE
055HFU
075HFE
075HFU
Applicable motor size *2 kW 0.4 0.75 1.5 2.2 3.0 4.0 5.5 7.5
HP1/2123457.510
Rated capacity (460V) kVA 1.1 1.9 2.9 4.2 6.2 6.6 10.3 12.7
Rated input voltage 3-phase: 380 to 415/400 to 460V ±10%, 50/60 Hz ±5%
Rated input current (A) 2.0 3.3 5.0 7.0 10.0 11.0 16.5 20.0
Rated output voltage *3 3-phase: 380 to 415/400 to 460V (corresponding to input voltage)
Rated output current (A) 1.5 2.5 3.8 5.5 7.8 8.6 13 16
Starting torque *6 200% or more 180% or more
Dynamic braking
approx. % torque,
short time stop *7
without resistor,
from 50/60 Hz
100%:
≤
50Hz
50%:
≤
60Hz
40%:
≤
50Hz
20%:
≤
60Hz
20%:
≤
50Hz
20%:
≤
60Hz
with resistor 150% 100% 80%
DC braking
Variable operating frequency, time, and braking force
Weight kg / lb 1.3/2.9 1.7/3.7 1.7/3.7 2.8/6.2 2.8/6.2 2.8/6.2
5.5/12.1 5.7/12.5
