“A” Group: Standard Functions
Configuring
Drive Parameters
3–12
Multi-speed Frequency Setting
The SJ100 inverter has the capability to store and output up to 16 frequencies to the
motor (A20 to A35). As in traditional motion terminology, we call this multi-speed
profile capability. Binary-encoded logic inputs select the particular frequency (speed)
setting, and the inverter applies the current acceleration or deceleration setting required
to change from the current output frequency to the new one. The first multi-speed setting
is duplicated for the second motor settings (the remaining 15 multi-speeds apply only to
the first motor).
The jog speed setting is used whenever the Jog command is active. The jog speed setting
range is arbitrarily limited to 10 Hz, to provide safety during manual operation. The
acceleration to the jog frequency is instantaneous, but you can choose from three modes
for the best method for stopping the jog operation.
A15 External frequency
offset enable
Two options; select codes:
00...Use offset (A11 value)
01...Use 0 Hz
✘
01 — F-31 IN
LEVEL
A16 External frequency
filter time constant
Range n = 1 to 8, where n =
number of samples for avg.
✘
8Sam-
ples
F-31 IN
F-SAMP
“A” Function
Run-
time
Edit
Defaults DOP,DRW,DOP+
Func.
Code
Name Description
EU/
US
Units
Func.
Code
Name
“A” Function
Run-
time
Edit
Defaults DOP,DRW,DOP+
Func.
Code
Name Description
EU/
US
Units
Func.
Code
Name
A20 Multi-speed
frequency setting
Defines the first speed of a
multi-speed profile, range is
0 to 360 Hz
A20 = Speed 1 (1st motor)
✔
0 Hz F-11 SPD FS
A220 Multi-speed
frequency setting,
2nd motor
Defines the first speed of a
multi-speed profile for 2nd
motor, range is 0 to 360 Hz
A20 = Speed 1 (2nd motor)
✔
0 Hz F-11 SPD 2FS
A21
to
A35
Multi-speed
frequency settings
(for both motors)
Defines 15 more speeds,
range is 0 to 360 Hz.
A21 = Speed 2...
A35 = Speed 16
✔
0 (all) Hz F-11 SPD 1
to
SPD 15
A38 Jog frequency setting Defines limited speed for jog,
range is 0.5 to 9.99 Hz
✔
1.0 Hz Mon. JOGGING
A39 Jog stop mode Define how end of jog stops
the motor; three options:
00...Free-run stop
01...Controlled deceleration
02...DC braking to stop
✘
00 — Mon. JOG
MODE
