“A” Group: Standard Functions
Configuring
Drive Parameters
3–20
NOTE: For A95 and A96 (and for 2nd motor settings), if you set a very rapid Acc1 or
Dec1 time (less than 1.0 second), the inverter may not be able to change rates to Acc2 or
Dec2 before reaching the target frequency. In that case, the inverter decreases the rate of
Acc1 or Dec1 in order to achieve the second ramp to the target frequency.
A94 Select method to use
second accel/decel
Two options for switching
from 1st to 2nd accel/decel:
00...2CH input from terminal
01...transition frequency
✘
00 — F-06 ACC
CHG
A294 Select method to use
second accel/decel,
2nd motor
Two options for switching
from 1st to 2nd accel/decel:
00...2CH input from terminal
01...transition frequency
(2nd motor)
✘
00 — F-06 2ACC
CHG
A95 Acc1 to Acc2
frequency transition
point
Output frequency at which
Accel1 switches to Accel2,
range is 0.0 to 360.0 Hz
✘
0.0 Hz F-06 ACC
CHFr
A295 Acc1 to Acc2
frequency transition
point, 2nd motor
Output frequency at which
Accel1 switches to Accel2,
range is 0.0 to 360.0 Hz
(2nd motor)
✘
0.0 Hz F-06 2ACC
CHFr
A96 Dec1 to Dec2
frequency transition
point
Output frequency at which
Decel1 switches to Decel2,
range is 0.0 to 360.0 Hz
✘
0.0 Hz F-07 DEC
CHFr
A296 Dec1 to Dec2
frequency transition
point, 2nd motor
Output frequency at which
Decel1 switches to Decel2,
range is 0.0 to 360.0 Hz
(2nd motor)
✘
0.0 Hz F-07 2DEC
CHFr
A97 Acceleration curve
selection
Set the characteristic curve of
Acc1 and Acc2, two options:
00...linear
01...S-curve
✘
00 — F-06 ACC
LINE
A98 Deceleration curve
setting
Set the characteristic curve of
Acc1 and Acc2, two options:
00...linear
01...S-curve
✘
00 — F-07 DEC
LINE
“A” Function
Run-
time
Edit
Defaults DOP,DRW,DOP+
Func.
Code
Name Description
EU/
US
Units
Func.
Code
Name
