SJ100 Inverter
Configuring
Drive Parameters
3–27
B89 Data select for digital
operator OPE-J
Select the monitoring data to
send to the hand-held digital
operator, seven option codes:
01...Output frequency (D01)
02...Output current (D02)
03...Motor direction (D03)
04... PID PV feedback (D04)
05...Input states for input
terminals (D05)
06...Output states for output
terminals (D06)
07...Scaled output frequency
(D07)
✔
01 — Mon. PANEL
B90 Dynamic braking
usage ratio
Selects the rate of use (in %) of
the regenerative braking
resistor per 100 sec. intervals,
range is 0.0 to 100.0%
0% .Dynamic braking disabled
>0% Enabled, per value
✘
00 % F-21 BRD-
%ED
B91 Stop mode selection Selects how the inverter stops
the motor, two option codes:
00... DEC (decelerate and stop)
01...FRS (free run to stop)
✘
00 — F-10 RUN STP
B92 Cooling fan control Selects when the fan is on per
inverter operation, two options:
00...Fan is always ON
01...Fan is ON during run,
OFF during stop
✘
00 — F-38 INIT
FAN-CTL
“B” Function
Run-
time
Edit
Defaults DOP,DRW,DOP+
Func.
Code
Name Description
EU/
US
Units
Func.
Code
Name
To Next Page
