“C” Group: Intelligent Terminal Functions
Configuring
Drive Parameters
3–30
Summary Table - this table shows all nineteen intelligent input functions at a glance.
Detailed descriptions of these functions, related parameters and settings, and example
wiring diagrams are in Chapter 4, starting on page 4–6.
Input Function Summary Table
Option
Code
Terminal
Symbol
Function Name Description
00 FW Forward Run/Stop
ON Inverter is in Run Mode, motor runs forward
OFF Inverter is in Stop Mode, motor stops
01 RV Reverse Run/Stop
ON Inverter is in Run Mode, motor runs reverse
OFF Inverter is in Stop Mode, motor stops
02 CF1 Multi-speed select,
Bit 0 (LSB)
ON Binary encoded speed select, Bit 0, logical 1
OFF Binary encoded speed select, Bit 0, logical 0
03 CF2 Multi-speed select,
Bit 1
ON Binary encoded speed select, Bit 1, logical 1
OFF Binary encoded speed select, Bit 1, logical 0
04 CF3 Multi-speed select,
Bit 2
ON Binary encoded speed select, Bit 2, logical 1
OFF Binary encoded speed select, Bit 2, logical 0
05 CF4 Multi-speed select,
Bit 3 (MSB)
ON Binary encoded speed select, Bit 3, logical 1
OFF Binary encoded speed select, Bit 3, logical 0
06 JG Jogging
ON Inverter is in Run Mode, output to motor
runs at jog parameter frequency
OFF Inverter is in Stop Mode
07 DB External DC Braking
ON DC braking will be applied during decelera-
tion
OFF DC braking will not be applied
08 SET Set Second Motor
ON The inverter uses 2nd motor parameters for
generating frequency output to motor
OFF The inverter uses 1st (main) motor parame-
ters for generating frequency output to motor
09 2CH 2-stage Acceleration
and Deceleration
ON Frequency output uses 2nd-stage accelera-
tion and deceleration values
OFF Frequency output uses standard acceleration
and deceleration values
11 FRS Free-run Stop
ON Causes output to turn off, allowing motor to
free run (coast) to stop
OFF Output operates normally, so controlled
deceleration stops motor
