Getting Started - 19 -
Note: If the OPEN lever is flat, the cover will not close.
Note: Always remove the battery from the camcorder after use.
Note: We cannot guarantee against malfunctions of the camcorder which occur when you
use battery packs other than those specified.
Note: Always attach a battery by the procedure described here. Attaching a battery forcibly
could damage it.
Removing the Battery Pack
1. Lift the OPEN lever and pull it up. The power supply attachment cover will open.
2. Push the side of the battery in the direction of the arrow. A click will be heard and the battery is
released.
3. Remove the battery and close the cover.
Checking the Battery's Charge
A battery charge indicator is located on the upper right corner of the viewfinder. One of three
symbols displays when the battery is used.
This symbol indicates a fully charged battery.
To Next Page
