Item Description
Primary
Volume
The SI P-VOL information.
Values:
• LDEV ID: The P-VOL's LDEV identification number. Click to open the LDEV
Properties window. Use this window to search for P-VOL information.
• LDEV Name: The P-VOL's LDEV name.
• Port ID: The port name of the P-VOL LDEV's LUN path. If the path is not defined,
a blank is displayed.
(VSP G1000, G1500, and VSP F1500) SI only. For SIz, a hyphen (-) is displayed.
• Host Group Name / iSCSI Target Alias: The host group name and ID or iSCSI
target alias and ID of the P-VOL LDEV's LUN path. If the path is not defined, a
blank is displayed.
(VSP G1000, G1500, and VSP F1500) SI only. For SIz, a hyphen (-) is displayed.
• iSCSI Target Name: The P-VOL's iSCSI target name. If the LUN path is not
defined, a blank is displayed.
(VSP G1000, G1500, and VSP F1500)SI only. For SIz, a hyphen (-) is displayed.
• LUN ID: The LUN identification number of the P-VOL LDEV's LUN path. If the path
is not defined, a blank is displayed.
(VSP G1000, G1500, and VSP F1500) SI only. For SIz, a hyphen (-) is displayed.
• Provisioning Type*: The P-VOL’s provisioning type.
○ Basic: Internal volume
○ DP: DP-VOL
○ External: External volume
○ External MF: (VSP G1000, G1500, and VSP F1500) Migration volume
• Emulation Type*: (VSP G1000, G1500, and VSP F1500) The P-VOL’s emulation
type.
• Attribute*: (VSP Gx00 models and VSP Fx00 models only) The P-VOL's attribute.
• Capacity*: The P-VOL's capacity.
• CLPR*: The P-VOL's CLPR ID.
• Encryption*: The P-VOL's encryption information.
○ Enabled: Encryption is enabled for the parity group to which the P-VOL's LDEV
belongs, or a V-VOL is associated with a pool in which a pool volume has
encryption enabled.
○ Disabled: Encryption is disabled for the parity group to which the P-VOL's
LDEV belongs, or a V-VOL is associated with a pool in which a pool volume has
encryption disabled.
○ Mixed: The pool to which the P-VOL's LDEV belongs contains two or more of
the following:
– Volume for which encryption is enabled
– Volume for which encryption is disabled
– External volume
Note: Data encryption is not ensured in an LDEV with Mixed encryption status.
(VSP G1000, G1500, and VSP F1500) If the LDEV is an external volume or
migration volume, a hyphen (-) is displayed.
For DP-VOLs, the pool to which an LDEV belongs is an external volume or blocked.
• Capacity Saving*: Information about the P-VOL's capacity saving function.
○ Compression: The compression function is used.
○ Deduplication and Compression: The deduplication function and the
compression function are used.
○ Disabled: The capacity saving function is not used.
• T10 PI*: The P-VOL's T10 PI attribute information.
○ Enabled: The P-VOL's T10 PI attribute is enabled.
○ Disabled: The P-VOL's T10 PI attribute is disabled.
