Hitachi VSP G1000

Item Description
• This icon is used for the following:
The pair is split.
Status:
○ SI: PSUS
○ SIz: Split/SUSPOP
You are splitting the pair in Quick Split mode.
Status:
○ SI: PSUS(SP)/PSUS
○ SIz: V-Split/SUSPVS
• The pair is suspended.
Status:
○ SI: PSUE
○ SIz: Suspend/SUSPER
For more information about SI or SIz pair status, see the System Administrator Guide.
Secondary
Volume
SI S-VOL information.
Values:
• LDEV ID: The S-VOL's LDEV identification number. Click to open the LDEV
Properties window.
• LDEV Name: The S-VOL's LDEV name.
• Port ID: The port name of the S-VOL LDEV's LUN path. If the path is not defined,
a blank is displayed.
(VSP G1000, G1500, and VSP F1500) SI only. For SIz, a hyphen (-) is displayed.
• Host Group Name / iSCSI Target Alias: The host group name and ID or iSCSI
target alias and ID of the S-VOL LDEV's LUN path. If the path is not defined, a
blank is displayed.
(VSP G1000, G1500, and VSP F1500) SI only. For SIz, a hyphen (-) is displayed.
• iSCSI Target Name: The S-VOL's iSCSI target name. If the LUN path is not
defined, a blank is displayed.
(VSP G1000, G1500, and VSP F1500) SI only. For SIz, a hyphen (-) is displayed.
• LUN ID: The LUN identification number of the S-VOL LDEV's LUN path. If the path
is not defined, a blank is displayed.
(VSP G1000, G1500, and VSP F1500) SI only. For SIz, a hyphen (-) is displayed.
• Provisioning Type*: The S-VOL’s provisioning type.
○ Basic: Internal volume
○ DP: DP-VOL
○ External: External volume
• Emulation Type*: (VSP G1000, G1500, and VSP F1500) The S-VOL’s emulation
type.
• Attribute*: (VSP Gx00 models and VSP Fx00 models only) The S-VOL's attribute.
• Capacity*: The S-VOL's capacity.
• CLPR*: The S-VOL's CLPR ID.
• T10 PI*: The S-VOL's T10 PI attribute information.
○ Enabled: The S-VOL's T10 PI attribute is enabled.
○ Disabled: The S-VOL's T10 PI attribute is disabled.
• Encryption*: The S-VOL's encryption information.
○ Enabled: Encryption is enabled for the parity group to which the S-VOL's LDEV
belongs, or a V-VOL is associated with a pool in which a pool volume has
encryption enabled.
○ Disabled: Encryption is disabled for the parity group to which the S-VOL's
LDEV belongs, or a V-VOL is associated with a pool in which a pool volume has
encryption disabled.
Thin Image GUI windows and wizards 233
Hitachi Thin Image User Guide for Hitachi Virtual Storage Platform G Series and F Series
