SPECIFICATIONS
12-21
Specifications
ZX300LC-6N
Model ZX300LC-6N
Type of Front-End Attachment 3.11 m (10 ft 2 in) Arm
Bucket Capacity (Heaped) PCSA 1.25 m
3
(1.64 yd
3
), CECE 1.10 m
3
Operating Weight 29200 kg (64400 lb)
Base Machine Weight 23000 kg (50800 lb)
Engine Isuzu AQ-6HK1XASA-02S 186kW/1900 min
-1
(253 PS/1900 rpm)
A :
Overall Width (Excluding back mirrors)
3190 mm (10 ft 6 in)
B :
Cab Height 3110 mm (10 ft 2 in)
C :
Rear End Swing Radius 3250 mm (10 ft 8 in)
D :
Minimum Ground Clearance *510 mm (20 in)
E :
Counterweight Clearance *1170 mm (3 ft 10 in)
F :
Engine Cover Height *2750 mm (9 ft 0 in)
G :
Overall Width of Upperstructure 2990 mm (9 ft 10 in)
H :
Undercarriage Length 4940 mm (16 ft 3 in)
I :
Undercarriage Width 3190 mm (10 ft 6 in)
J :
Sprocket Center to Idler Center 4052 mm (13 ft 4 in)
K :
Track Shoe Width 600 mm (24 in) (Grouser shoe)
Ground Pressure 55 kPa (0.56 kgf/cm
2
, 8.0 psi)
Swing Speed 10.3 min
–1
(rpm)
Travel Speed (fast/slow) 5.5/3.3 km/h (3.4/2.0 mph)
Gradeability 35 ° (tanθ = 0.70)
f
NOTE: * The dimensions do not include the height of the shoe lug.
MDAA-12-001
A
G
B
D
K
I
C
F
E
J
H
