22
Other Information Displayed During the Process
Pressing the INC or DEC buttons during the charging or discharging process al-
lows you to see a variety of other information on the screen.
Final voltage at the end of the program.
Input voltage from internal or external power source.
Internal and external temperatures. External Tempera-
ture requires optional temperature sensor. #44159
Cut-o temperature when using external temperature
sensor.
Safety timer ON and duration of time in minutes.
Capacity cut-o ON and set value of the capacity limit.
12.6V (3S)
End Voltage
14.82V
IN Power Voltage
Int. Temp 37°C
Ext. Temp ----
50°C
Temp Cut-Off
ON 120min
Safety Time
Capacity Cut-Off
Program Stop
During the charging process, press STOP button to stop the process.
Program Complete
When the discharging process is nished, an audible
sound will be heard and the charger will indicate
END: FINSHED. The charger displays the total pack
voltage, total mAh drawn from the battery and the
elapsed time of the process.
NOTE: The battery charge indicator displays Green during charging and Red
during discharging.
[ END: FINISH ]
12.60V 02001mAh
TIME: 00:32:15
12.60V 02001mAh
Lithium Battery Program (continued)
66
66
ON 5000mAh
