Chapter 1 Linear Actuator LA Series User's Guide
1. Product Specification
1.1 Standard Performance:
TYPE
Max.
Push Force
(N)
Max.
Pull Force
(N)
Max. Cyrrent(A)
Max Holing
Force (N)
Speed
(mm/s)
12VDC 24VDC
LAM1-1 4000 3000 12 6 4000 8-11
LAM1-2 2000 2000 12 6 1200 16-21
LAM1-1A 3000 3000 12 6 3000 8-11
LAM2-1 3500 3500 8 4 3000 2-3.5
LAM2-2 2500 2500 8 4 2000 3-6
LAM2-3 1500 1500 6 3 1500 6.5-12
LAM3-1 6000 5000 12 6 5000 4-5.5
LAM3-2 4000 4000 10 5 4000 5.5-7.5
LAM3-4 2000 2000 8 4 1500
11.5-14.5
LAS1-1 1200 1200 6 2.5 800 8-12
LAS1-2 600 600 6 3 300 16-25
LAS2-1 1800 1200 6 3 1800 4.5-7
LAS3-1 1200 1200 6 2.5 800 8-12
LAS3-2 600 600 6 3 300 16-25
LAS4-1 800 800 5 2.3 600 10-15
LAS4-2 300 300 6 3.6 200 30-46
LAN1-1 5000 5000 11 5000 3-6
LAN1-2 4000 4000 11 4000 4-8
LAN1-3 3000 3000 10 3000 5-10
LAN3A-1 12000 6000 8.3 6000 24VDC 24VDC(24Q)
3-5 4.5-7
LAN3A-2 10000 6000 8.3 6000 4.5-8 7-11
LAN3A-3 7000 6000 8 6000 7-9 9-13
LAN3A-4 5000 5000 7 5000 9.5-12.5 13-18
LAN4-1
3500 3500 12 6 3500 3.5-7
LAN4-2 3000 3000 12 6 3000 4.2-9
LAN4-3 2000 2000 12 5 2000 6-13
LAN4-4 1500 1500 12 5 1500 8.5-20
