HLU HF R 48 R Series - Tightening Torques for Bolt Connections; Vibrations

34
06.2019
Vibration values according to ISO 14694
Stan-
dard
group
ISO
14694
Motor
power
[kW]
Min.
balan-
cing
quality
Limit values
At manufacturer
Average values;
maximum values
in brackets
In operation
Average values;
maximum values
in brackets
Fixed
mounted
[mm/s]
Flexibly
mounted
[mm/s]
Fixed mounted
[mm/s]
Flexibly mounted
[mm/s]
BV-2 >0.15<3.7 G16 3.5 (5.1) 5.6 (7.6)
Start-up 5.6 (7.6)
Alarm 9.0 (12.2)
Slow-down 10 (14)
Start-up 9.0 (12.7)
Alarm 14.0 (19.1)
Slow-down 16 (21)
BV-3 >=3.7<37 G6.3 2.8 (3.8) 3.5 (5.1)
Start-up 4.5 (6.4)
Alarm 7.1 (10.2)
Slow-down 9.0 (12.7)
Start-up 6.3 (8.8)
Alarm 11.8 (16.5)
Slow-down 12.5 (17.8)
BV-4 >=37<300 G2.5 1.8 (2.5) 2.8 (3.8)
Start-up 2.8 (4.1)
Alarm 4.5 (6.4)
Slow-down 7.1 (10.2)
Start-up 4.5 (6.4)
Alarm 7.1 (10.2)
Slow-down 11.2 (15.2)
8.6 Tightening torques for bolt connections
On the basis of VDI 2230 the following tightening torques are recommended for bolts of strength
class 8.8:
Nominal
diameter [mm]
Tightening
torques [Nm]
M4 3,3
M5 6,5
M6 11,3
M8 27,3
M10 54
Nominal
diameter [mm]
Tightening
torques [Nm]
M12 93
M16 230
M20 464
M24 798
International standards for the balancing quality and vibration values for industrial fans are de-
ned in the standard ISO 14694:2003. The vibrations are measured radially on the shaft bearing
of the drive motor. If a measurement is not possible directly on the motor, it is measured radially
at the next point that has a mechanical connection to the motor. The following table shows the
fan application categories for maximum permissible vibration.
Operating manual
Centrifugal fans
HF R | RV | MRV
www.hlu.eu
8.5 Vibrations
