3.1 General data
Ambient temperature range
The specications on the type label are applicable. If they are missing, the temperature range
is - 20 °C to + 40 °C.
Noise level
For the value applicable to each fan, see the manufacturer internet site, or contact us via phone.
Operating manual
Centrifugal fans
HF R | RV | MRV
Type ØD
max.
A
Direct drive Belt drive
max.
B
max.
X
max.
kg.
max.
RB
max.
RX
max.
kg
RV 45/63-160 160 400 500 500 6 550 950 22
RV 45/63-200 200 500 600 550 9 600 1000 23
RV 45/63-250 250 650 750 680 15 700 1100 32
RV 45/63-315 315 800 900 720 25 850 1300 46
RV 45/63-355 355 900 950 780 30 900 1450 55
RV 45/63-400 400 1000 1100 1100 65 1100 1850 120
RV 45/63-450 450 1100 1150 1150 125 1150 1850 150
RV 45/63-500 500 1200 1350 1300 95 1350 2000 200
RV 45/63-560 560 1350 1400 1350 170 1400 2000 150
RV 45/63-630 630 1500 1700 1500 265 1700 2250 355
RV 45/63-710 710 1700 1750 1650 1750 2350
RV 45/63-800 800 1900 2100 2100 480 2100 2850 560
RV 45/63-900 900 2150 2200 2200 2200 2950
RV 45/63-1000 1000 2400 2650 2300 720 2650 3150 1000
RV 45/63-1120 1120 2700 2750 2450 2750 3300 1040
RV 45/63-1250 1250 3000 3050 2550 3050 3500
Type ØD
max.
A
Direct drive Belt drive
max.
B
max.
X
max.
RB
max.
RX
MRV 45/63-160 160 450 600 550 650 950
MRV 45/63-200 200 550 750 600 750 1000
MRV 45/63-250 250 650 900 700 850 1100
MRV 45/63-315 315 800 1100 1000 1050 1300
MRV 45/63-355 355 850 1150 1050 1100 1450
Others
More relevant data are given on the type label.
The service life of bearing is depending on the load at > 25 000 h.
