6
06.2019
2.1 Construction of the fans
2. Construction and correct use for the intended application
Operating manual
Centrifugal fans
HF R | RV | MRV
www.hlu.eu
Fig. 1a| Overview of the fan HF R ...-15 / 17 D | Direct drive
Motor
Impeller
Housing
Housing cover with
inlet adapter
Frame
Condensate drain
Outlet adapter
Vibration absorber
Fig. 1b| Overview of the fan HF R ...- 16 / 13 D | Direct drive
Impeller
Housing cover with
inlet adapter
Outlet adapter
Motor
Frame
Vibration absorber
Condensate drain
Housing
Sleeve
Sleeve
Sleeve
Sleeve
