Operating manual
Centrifugal fans
HF R | RV | MRV
Fig. 1c| Overview of the fan HF R ...-48 R | Belt drive
Motor
Housing
Impeller
Housing cover with
inlet adapter
Frame
Outlet adapter
Vibration absorber
Sleeve
Sleeve
Flange bearing
Condensate drain
Belt drive
drive cover
