Operating manual
Centrifugal fans
HF R | RV | MRV
Fig. 1e| Overview of the fan HF RV / MRV | Belt drive
Designation Designation
1 Frame 9 Belt pulley, Motor
2 Motor-clamp 10 V-Belt
3 Support 11 Shaft cover
4 Vibration dampers 12 Driver cover
5 Motor 13 Housing
6 Bearing 14 Housing cover with inlet adapter
7 Shaft 15 Impeller
8 Belt pulley, Fan
