Fig. 8
BOWL LIFT SLIDE-WAYS
The Slideways (Fig. 8) should be lubricated once each month. Remove the apron (secured by four
thumb screws) from the front of the pedestal. Lightly coat both Slideways with Lubriplate 630AA
(supplied). Replace the apron and thumbscrews.
SERVICE
If service is needed on this equipment, contact your local Hobart Service Office.
PL-40172-1
Bowl Lift Slideways
FORM 34926 (June 2005) PRINTED IN U.S.A.
1. Gear Shift Lever between gears (not fully
engaged).
2. Circuit protector in open position — check fuse
or disconnect switch.
3. Bowl not all the way up.
4. Wire Cage Assembly is not in the Front-Center
Position.
5. Mixer or attachment overloaded.
TROUBLESHOOTING
SYMPTOMS POSSIBLE CAUSES
Mixer will not start.
D340 Mixer Technical Manual Page 18 of 67
