MODEL H600/P660/L800 GENERAL
F12536 (Rev. A, December 2005)Page 5 of 88
OPERATING SPEEDS (RPM)
SPEED
H600 L800 P660 P660 SBA
AGITATOR ATTACHMENT AGITATOR ATTACHMENT AGITATOR ATTACHMENT AGITATOR ATTACHMENT
First 70 79 60 68 56 175 78 294
Second 124 139 106 119 99 305 - - - - - -
Third 206 232 177 199 - - - - - - - - - - - -
Fourth 362 408 311 350 - - - - - - - - - - - -
OVER-ALL DIMENSIONS AND WEIGHT W/ STANDARD BOWL
H600 L800 P660
Height 55 7/8" 55 7/8" 55 7/8"
Width 27 1/2" 27 1/2" 27 1/2"
Length 39 1/4" 41 1/2" 39 1/4"
Net Weight (Lbs.) 853 / *675 875 / *675 853
Net Wt. w/Power Bowl Lift
(Lbs.)
878 / *700 900 / *700 - - -
* Represents weight of H600-D and L800-D mixers.
LUBRICATION
WARNING: DISCONNECT THE ELECTRICAL POWER TO THE MACHINE AND FOLLOW
LOCKOUT / TAGOUT PROCEDURES.
NOTE: Lubricants listed are those specified at time of printing this manual. Refer to the current revision of
Lubrication Manual F-20067 for the latest lubrication requirements.
LUBRICATION CHART
Component Lubricant Quantity
Transmission Case Mobile Gear 634 128 Fl. oz.
Planetary and Internal Gears
1
Exxon Spartan EP150 6 Fl. oz.
Planetary
2
Chevron FM EP NLGI 2 4 Fl. oz.
Motor Bearings Prelubricated - - -
Slideways Lubriplate 630AA Lightly Coat
Bowl Lift Gearing
3
Chevron FM EP NLGI 2 Coat
Bowl Lift Screw Lubriplate 630AA Coat
1
Applies to mixers equipped with a planetary oil pump.
2
Applies to mixers built without a planetary oil pump.
3
Original lubricant was Marfak #0. For compatibility reasons, remove at least 90% of the
previous lubricant before installing current lubricant.
