7
FIG 8
FIG 9
Mounting Swivel Cam Cleat and Mount
5
Hold Cheek Block on the
stern, starboard side of the
kayak just behind the metal
plate, drill holes using a
3/16’’ drill bit. (FIG 8)
Through bolt the 1’’ and
1.5’’ machine screws using
the provided washers and
nuts by reaching through
the rear hatch of the kayak.
(FIG 9)
Drill with 3/16
Thru-Bolt
To Next Page
