Hobie Mirage Compass Instruction Manual

5
Installation
Create a 3/8” hole just below each end of the paddle groove on the
starboard side, or at the same location and spacing on the port side,
depending on your preference. Use the correct hardware assemblies to
mount an eyelet post at each of these holes. This will act as a line guide,
keeping your trolley line clear of the paddle on the starboard (right) side
or steering handle on the port (left) side of the kayak. THE EYELET POSTS
SHOULD BE LOCATED ABOVE THE WATER LINE.
4
#10-32 X 1 1/2”
Pan

Hobie Mirage Compass Specifications

General

Fitted Hull Weight	68 lbs / 31 kg
Capacity	400 lbs / 181 kg
Hull Construction	Rotomolded Polyethylene
Seat	Vantage CT
Length	12 ft / 3.66 m
Width	34 in / 0.86 m
Storage	Front Hatch, Rear Cargo Area
Vantage Seat Capacity	275 lbs / 125 kg
