Rudder Installation
There are steering tracks lo-
cated on both sides of the seat.
Choose which side is best for
you.
Slide the steering handle onto
the track over the lock pin. The
pin will click into place.
Point the steering handle in
the direction you would like to
travel.
To remove the steering handle,
pull down on the red knob
located on the underside of the
steering track and slide the
handle off the track.
Steering
1
2
3
4
Connect the hook on the rudder up/
down line to the padeye mounted on
the back of the seat bottom frame.
1
Once the up/down line is connected,
pull up on the line to flip the rudder
down and back up.
2
Rudder UP/DOWN
Pull
