Hobie Mirage Lynx User Manual

17
hobie.com
NOTE: The transducer
hardware kit is an optional
accessory and is not included
with the Lynx.
Transducer Install
Accessory Options
To take off the plate on the
bottom of the hull, remove the
screws using a hand Phillips
screwdriver.
Follow instructions on your
Fishfinder kit for installation.
Cup Holder
PowerPole Mount
Place on the opposite side of the steering handle.
Remove the PowerPole scupper cover plates and install the PowerPole
Mount to the molded inserts from the Lynx PowerPole Hardware Kit.

Hobie Mirage Lynx Specifications

General

Length	11' (3.35 m)
Width	36" (0.91 m)
Capacity	350 lbs (159 kg)
Drive	MirageDrive 180
Crew	1
Weight	57 lbs (25.9 kg)
Rudder System	Kick-Up Rudder
