Hobie Mirage Lynx User Manual

8
Seating
1
2
There are two con-
nection points on the
kayak to secure the
seat.
Connect the rear
seat bottom frame
into the seat holders
on the back of the
kayak.
Push down on the
seat until it snaps
into the holders.
Secure by stretch-
ing the shock cord
over the seat bottom
frame and loop-
ing the shock cord
around the hook
built into the seat
holder.
Connect the hooks
on the left and right
straps that hang off
the front of the seat
to the leash plugs
molded in the kayak.
Pull the Left and
Right straps tight to
secure the seat in
place.
1
2
Installation

Hobie Mirage Lynx Specifications

General

Length	11' (3.35 m)
Width	36" (0.91 m)
Capacity	350 lbs (159 kg)
Drive	MirageDrive 180
Crew	1
Weight	57 lbs (25.9 kg)
Rudder System	Kick-Up Rudder
