26
Fishfinder Option
1
Once the transducer is installed, feed the
transducer cable through the scupper hole above
the cavity and screw the plate back into place.
You should now have the transducer cable acces-
sible in the cockpit of the kayak.
TIP: Lubricate the cable with soapy water to allow it to slide through
the rubber adapter more easily.
NOTE: Rubber adapters can be found in the kayak owner’s manual.
Run the Transducer Cable
2
Remove the plug next to the scupper above the transducer cavity using
a phillips head screwdriver. Feed the cable through the gasket and
into the hull. Find the rubber adapter that matches the diameter of the
transducer cable and fit it to the cable. Attach the adapter and cable
to the plug and reinstall. Be careful not to overtighten and strip the
screws.
