Hofmann Megaplan MS400-2 - Page 52

18
Lock the nut (and relative washer pack) of the
dynamic piezo (with a 400 kg.cm torque wrench)
19
Tension the tie-rod of the static piezo screwing
down the nut and then turn it a further 180°
20
Check that the nut that joins the threaded bars is
locked with a 400 kg.cm torque wrench
180°
