E codes (CRT/HNA/HWT)
ui_error.h revision 1.11
E Internal code(s) Description
0
E1 Rim dimensions entered incorrectly
E2 Wheel guard is not closed
E3 Gauge arm not in home position
E4 Outer gauge arm not in home position
E5 Range of electrical unbalance compensation exceeded (residual
adapter unbalance)
E6 0x812560, 0x812561,
0x812565, 0x812566
Calibration weight not attached to flange
E7 No balancing mode for this wheel type
E8 Valve position was not entered
E9 Optimisation was carried out incorrectly
10
E10 Wheel guard is not open, wheel may not be clamped / unclamped
E12 Not available to date Pedal is operated, measuring run not possible
E13 Not available to date The clearance of the solenoid brake is too wide.
E14 The power clamping device is not clamped
E15 Corrective terms for readjustment are out of range
E16 0x812570, 0x812571 Calibration weight attached erroneously to flange
E17 0x492207 Wheel slipped on adapter
20
E28 0x492205 Wrong direction of rotation (hand spin)
E29 Speed too high (hand spin ?)
30
E30 Run-out measurement failed
E31 Rim only mounted during geometric matching when rim and tyre
expected.
80
E83 Vibration of the machine disturbed the unbalance measurement
E85 Power clamp service interval expired
E88 0x492208 The rotating speed of the main shaft exceeds the safety limit
E89 Key contact or pedal switch closed
90
E92 0x441350, 0x441351,
0x441360, 0x441361
The inner gauge arm for distance and rim diameter is defective
E93 0x441370, 0x441371 The outer gauge arm for rim width is defective
100
E101 0xC30E01 ASA: Status of an activeted order has changed due to network
manager or shop management software activities.
140
