C80 SAPE Arm Calibration (b9460)
Displayed on selection:
The digit "1" in the left display to indicate the step number.
Step 1 options:
Pressing the RETURN key will store the home position of the SAPE arm offset.
Step 2 options:
The digit "2" in the left display to indicate the step number.
Pressing the RETURN key will store the fully extended position of the SAPE arm.
Step 3 options:
The digit "3" in the left display to indicate the step number.
Pressing the RETURN key will store the rotary position of the SAPE arm when resting on the bottom of
the calibration weight.
Step 4 options:
The digit "4" in the left display to indicate the step number.
Pressing the RETURN key will store the rotary position of the SAPE arm when resting on the top of the
calibration weight and exit the service code.
Pressing the PLUS and MINUS keys together at any stage will act like an Escape key and exit the code.
C81 Flange position calibration (b9460)
Displayed on selection:
The digit "1" in the left display to indicate the step number.
Step 1 options:
Pressing the RETURN key will store the distance of the flange from the machine cabinet as entered by
the inner sape and exit the service code.
Pressing the PLUS and MINUS keys together at any stage will act like an Escape key and exit the code.
