5.20Pneumatictyres
Yourrehabpushchaircanbeequippedwithpneumatictires.The
carvalvesallowcheckingandadjustingtheairpressureateachgas
station.Noticetheairpressureindicatedonthetyre.
6 Accessories
Strapsonaccessoriesareusuallyextralongtoaccommodateeveryoption.
Excessstrapendsonaccessoriesmaybetrappedbetweenthetwopartsoftheseatmounting
interfaceandpreventafullengagementofthelockpin.Insuchacasetheseatcouldfalloffthe
mobilitybase.Shortenexcessstrapendsonaccessoriessothattheycannotbetrapped.Toprevent
strapendsfromfrayingthecutendscanbemeltedtogetherwithaame.(eg.cigarettelighter)
Allaccessoriesnotinstalledbythemanufacturermustbeinstalledbytrainedtechnicians.
Thefollowingnotesoninstallationareforyourinformationbutshouldbeperformedbytrainedtechnicians.
5.19 ASS Adaptive suspension system
The BINGO Evolutioncanbesuppliedwitanadjustable(4steps),
adaptiveframesuspensionsystem(ASS).
Differentspringsetsareavailable:
-springsetforBINGO Evolution Miniupto15kg
-springsetforaloadcapacityupto25kg
-springsetforaloadcapacityover25kg
Thescalingonthesuspensionhousingservesasaguide.Thenumber
visiblefromtheoutsiderepresentsthesetlevel.
5.18Detachingwheelswithquickrelease
Therearwheelsofallframevariantsandthefrontwheelsoftherigid
framevariantcanberemovedwithquickfasteners.Thus,aneven
smallerfoldingsizebeachieved.
•Todetachpressthequickreleasespringtowardsthemiddleofthe
wheelandpullthewheelfromtheaxle.
