6.25Attendantbrake
The BINGO Evolutionmobilitybasecanbettedwithanattendant
brake.Thebrakemechanismcanbeoperatedwithasingleleveranda
cableswitchorwithtwoindependentbrakelever.
Canopywithraincover:
Taketheraincoveroutofthebagattachedtothewrap,unfoldtherain
cover,pullitovertheunfoldedcanopyandputitoverthefootrest
assembly.
Theangleadjustmentofthebackrestislimited
becauseofthetransparentraincover.Theangle
adjustmentisadaptedtoaseatandkneeangleof
90°.Usethespaceintiltfunctiontoadjustastationary
position.(see5.17).
Adjustableratchetjointsareusedtosettheangleofthecanopy.
•Spreadthecanopyandwrapoverthebackrestoftheseat.
•Tightenthecanopyadaptersrmly.Proceedinthesamewayonthe
otherside.
•Insertthemalepinsofthecanopyintothecanopyadaptersonboth
sides.
