•Placeyourchildintothepushchaironthegroinstrap.
•Thethighstrapsarepassedbetweenthelegsthroughandover
thethighs,atthatthepartofthethighbeltwiththebuckleattached
shouldlieonthepelvicbone.
•Insertthemalepartofthequick-releasebuckleslocatedonthe
tensioningstrapsintothebucklesonthethighbelts.
•Tightenthethighbeltbypullingthefreeendofthestrapthatcomes
outofthebuckle.
•Todisengagethequickreleasebuckle,pressthekeyonthebuckle.
Caution!
Excessstrapendsonaccessoriesmaybetrappedin
thetiltmechanismandcanavoidtheengagementof
thelockingpins.Insuchacasetheseatcouldfalloff
themobilitybase.Shortenexcessstrapendson
accessoriessothattheycannotbetrapped.
Toputonthegroinstrapproceedasfollows:
Openingthexationjacket:
•Openthequick-releasebucklesontheshoulderpartofthexation
jacket.
•Pullthezipperdownandopenthexationjacket.
•Liftyourchildoutoftheseat.
6.15Fixationjacket
Toattachthexationjacketstraps,rivet(frominsidetooutside)thesix
cam-lockbucklestotheoutsideofthebackplate.
Threadtheshoulderstrapsofthexationjacketthroughtheshoulder
slotstotherear.Thecentre“axillarystraps“mustbethreadedatthe
appropriateheightbetweenthebackframetubeandbackplate.Thread
thelowerstrapsthroughtheslotsinthelowerpartofthebackbase
(seealso6.9Lapbelt)totherear.
Threadallstrapsthroughtheopencam-lockbucklesandclampin
positionbyclosingthehingedcam.
Caution!
Excessstrapendsonaccessoriesmaybetrappedin
thetiltmechanismandcanavoidtheengagementof
thelockingpins.Insuchacasetheseatcouldfalloff
themobilitybase.Shortenexcessstrapendson
accessoriessothattheycannotbetrapped.
